Ideal Strength for Residential & Commercial Projects
Bhrata TMX is one of the leading FE 550 TMT Bars manufacturer and supplier in Gujarat, India. Our TMT (Thermo Mechanical Treated) steel bars are developed to provide durability, tensile strength and superior ductile to the construction sector. These TMT bars are produced using advanced technology and an uncompromising quality approach. We are committed to provide precisely tailored, premium quality products to fulfil client requirements.
Get Best Price →
When it comes to building structures that last - and last with integrity - the right choice of reinforcement is everything. Fe 550 TMT Bars are the gold standard, leading the pack in strength, flexibility, and overall durability. From the residential to large-scale infrastructure projects - these TMT bars provide the reliability that modern construction demands.
As a trusted Fe 550 TMT Bars manufacturer and supplier in Gujarat, we're dedicated to delivering top-shelf products that meet the highest industry standards and deliver exceptional performance across all sorts of applications.
Fe 550 grade steel stands for Thermo-Mechanically Treated (TMT) bars with a minimum yield strength of 550 N/mm². Or in simple terms: Fe for Ferrum (that's iron) and 550 pointing to the bar's yield strength.
What makes these bars so special? Well, they're created using a highly advanced process called TMT, where the steel is rapidly quenched then self-tempered to give the bar a seriously tough outer surface and super ductile inner core. This is what sets them apart and makes them ideal for harsh construction environments.
Compared to the lower grades, Fe 550 really stands out with a much higher load-bearing capacity. Builders end up needing to use less steel without sacrificing any strength at all.
One of the standout qualities of Fe 550 TMT Bars is that perfect combination of strength and flexibility.
With a yield strength of 550 N/mm², these TMT bars can handle massive loads and high stress, making them perfect for high-rise buildings and structural frameworks.
FE 550 TMT bars are not just strong - they also have incredible flexibility. In other words, they can absorb shocks and vibrations which is especially useful in earthquake-prone areas.
Apart from this, they are capable of enduring higher temperatures, which makes them more fire resistant.
Ribbing helps make a bond between the bar and concrete that makes up a very strong building.
Fe 550 can sustain their strength even if put under constant stress, which is why they are perfect for use in dynamic loads like bridges and industrial buildings.
| ELEMENT | FE 550 | FE 550 D | FE 600 | |||
|---|---|---|---|---|---|---|
| BIS | BHARATA TMX 550 | BIS | BHARATA TMX 550 D | BIS | BHARATA TMX 600 | |
| CARBON% | 0.30 | 0.25 | 0.25 | 0.24 | 0.25 | 0.22 |
| SULPHUR% | 0.055 | 0.050 | 0.040 | 0.040 | 0.040 | 0.035 |
| PHOSPHORUS% | 0.050 | 0.040 | 0.040 | 0.035 | 0.040 | 0.035 |
| S+P% | 0.100 | 0.090 | 0.075 | 0.070 | 0.075 | 0.070 |
| GRADE | FE 550 | FE 550 D | FE 600 | |||
|---|---|---|---|---|---|---|
| BIS | BHRATA TMX | BIS | BHRATA TMX | BIS | BHRATA TMX | |
| YIELD STRESS | 550 | 570 | 550 | 570 | 600 | 620 |
| TENSILE STRESS-UTS | 585 | 630 | 600 | 630 | 660 | 670 |
| UTS/YS RATIO | 1.06 | 1.01 | 1.08 | 1.06 | 1.06 | 1.08 |
| ELONGATION % | 10 | 14.5 | 14.5 | 16 | 10 | 12 |
| TOTAL ELONGATION AT MAX FORCE% | - | - | 5 | 6 | - | - |
| TEST | FE 550 | FE 550 D | FE 600 | |||
|---|---|---|---|---|---|---|
| BIS | BHRATA TMX 550 | BIS | BHRATA TMX 550 D | BIS | BHRATA TMX 660 | |
| BEND UPTO 20MM | 5 D | 4 D | 4 D | 4 D | 5 D | 5 D |
| BEND OVER 20MM | 6 D | 5 D | 6 D | 5 D | 6 D | 5 D |
| RE-BEND UPTO 10MM | 7 D | 8 D | 6 D | 6 D | 7 D | 7 D |
| RE-BEND OVER 10MM | 8 D | 7 D | 7 D | 7 D | 8 D | 8 D |
| Specific Weight | BIS Standard | BHRATA TMX | |
|---|---|---|---|
| SIZE MM | Kg/Mtr. | Kg/Mtr. | Kg/Mtr. |
| 8 MM | 0.395 | 0.367-0.423 | 0.368-0.393 |
| 10 MM | 0.617 | 0.574-0.660 | 0.575-0.610 |
| 12 MM | 0.888 | 0.844-0.960 | 0.845-0.935 |
| 16 MM | 1.580 | 1.501-1.659 | 1.502-1.570 |
| 20 MM | 2.470 | 2.396-2.544 | 2.400-2.435 |
| 25 MM | 3.850 | 3.735-3.965 | 3.740-3.820 |
| 28 MM | 4.850 | 4.687-4.975 | 4.700-4.810 |
| 32 MM | 6.310 | 6.121-6.499 | 6.150-6.250 |
| 40 MM | 9.860 | 9.564-10.165 | 9.564-10.155 |
Fe 550 TMT bars are highly applicable and beneficial in many construction areas.
These TMT bars are the most suitable to be used in residential construction as they provide strength and security to your homes, villas and apartments.
Fe 550 TMT bars ensure strength and security in office buildings, shopping centres and other heavy buildings.
They offer the perfect quality in case of high rise buildings requiring strength for bearing loads.
Fe 550 TMT bars ensure strength and safety in projects including flyovers, bridges and highways.
It includes warehouses and factories and all other types of heavy load-bearing constructions.
Well, if you think Fe 500 TMT bars are good then check this difference with Fe 550 bars. This is what makes them different:
Fe 550 bars deliver greater yield strength, which means you can use less steel without sacrificing safety.
They can handle higher loads, making them perfect for modern construction projects.
The enhanced ductility & strength combo really comes into its own when it's all about withstanding natural disasters like earthquakes.
True, they might be a bit pricier upfront, but the FE 550 bars are capable of using less material, meaning long term savings down the line.
FE 550 TMT Bars have a solid resistance to wear & environmental stress, which means a longer lifespan for the structures they're in.
Builders & contractors increasingly go for Bharat FE 550 TMT bars because they are best and reliable.
They are stronger, less steel is required which means overall project costs come right back down.
You might expect them to be harder to bend & shape because of their strength but actually the opposite is true, making construction a faster & more efficient process.
Using the advanced technology to make them, Bhrata FE 550 bars offer consistent quality every time, each time.
Structural engineers prefer these bars because they behave just as they're supposed to & meet industry standards with ease.
All of these benefits add up to FE 550 TMT bars being smart investments for any construction project, especially when safety & longevity are top priorities.
Known as the reputed FE 550 TMT Bars manufacturer in Gujarat and Rajasthan, we focus mainly on quality, reliability, and excellence. Made from advanced German technology our offered FE 550 TMT Bars are known for their super strength, durability and ductility. You can get premium quality Bhrata FE 550 TMT bars while searching "Best TMT Bars in Gujarat" as we consistently provide best quality at market leading prices.
